MHQ0402PSA2N0ST000 TDK

INDUCTORS Inductors for high frequency circuits Cl Pb Br Multilayer ceramic REACH Halogen Lead RoHS SVHC-Free Free Free MHQ-PSA series MHQ0402PSA type FEATURES Unique ceramic material and configuration allows for the realization of high Q characteristics. Multilayer method allows for a lineup with fine increments of inductance. Operating temperature range: 55 to +125C APPLICATION Smart phones, tablet terminals, high frequency modules (PAs, VCOs, FEMs , etc.), Bluetooth, W-LAN, UWB, tuners and other high fre- quency circuits for the mobile communication industry Application guides: Smart phones/tablets PART NUMBER CONSTRUCTION MHQ 0402 PSA 0N2 B T 000 LWH dimensions Inductance Inductance Series name Characteristics Packaging style Internal code 0.40.20.2 mm (nH) tolerance Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. (1/13) Please note that the contents may change without any prior notice due to reasons such as upgrading. 20181220 inductor_commercial_high-frequency_mhq0402psa_en.fmINDUCTORS MHQ0402PSA type CHARACTERISTICS SPECIFICATION TABLE L L measuring Q Q measuring Self-resonant DC resistance Rated current Part No. frequency frequency frequency (nH) Tolerance (MHz) min. (MHz) (GHz)min. (GHz)typ. ( )max. ( )typ. (mA)max. 0.2 0.1nH 500 500 10 20.00 0.15 0.02 600 MHQ0402PSA0N2BT000 0.2 0.2nH 500 500 10 20.00 0.15 0.02 600 MHQ0402PSA0N2CT000 0.3 0.1nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N3BT000 0.3 0.2nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N3CT000 0.4 0.1nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N4BT000 0.4 0.2nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N4CT000 0.4 0.3nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N4ST000 0.5 0.1nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N5BT000 0.5 0.2nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N5CT000 0.5 0.3nH 500 500 10 20.00 0.15 0.04 600 MHQ0402PSA0N5ST000 0.6 0.1nH 500 500 10 20.00 0.15 0.05 600 MHQ0402PSA0N6BT000 0.6 0.2nH 500 500 10 20.00 0.15 0.05 600 MHQ0402PSA0N6CT000 0.6 0.3nH 500 500 10 20.00 0.15 0.05 600 MHQ0402PSA0N6ST000 0.7 0.1nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N7BT000 0.7 0.2nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N7CT000 0.7 0.3nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N7ST000 0.8 0.1nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N8BT000 0.8 0.2nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N8CT000 0.8 0.3nH 500 500 10 20.00 0.15 0.06 600 MHQ0402PSA0N8ST000 0.9 0.1nH 500 500 10 20.00 0.15 0.08 600 MHQ0402PSA0N9BT000 0.9 0.2nH 500 500 10 20.00 0.15 0.08 600 MHQ0402PSA0N9CT000 0.9 0.3nH 500 500 10 20.00 0.15 0.08 600 MHQ0402PSA0N9ST000 1.0 0.1nH 500 10 500 10 18.84 0.15 0.07 600 MHQ0402PSA1N0BT000 1.0 0.2nH 500 10 500 10 18.84 0.15 0.07 600 MHQ0402PSA1N0CT000 1.0 0.3nH 500 10 500 10 18.84 0.15 0.07 600 MHQ0402PSA1N0ST000 1.1 0.1nH 500 10 500 10 20.00 0.15 0.11 500 MHQ0402PSA1N1BT000 1.1 0.2nH 500 10 500 10 20.00 0.15 0.11 500 MHQ0402PSA1N1CT000 1.1 0.3nH 500 10 500 10 20.00 0.15 0.11 500 MHQ0402PSA1N1ST000 1.2 0.1nH 500 10 500 10 16.72 0.20 0.15 500 MHQ0402PSA1N2BT000 1.2 0.2nH 500 10 500 10 16.72 0.20 0.15 500 MHQ0402PSA1N2CT000 1.2 0.3nH 500 10 500 10 16.72 0.20 0.15 500 MHQ0402PSA1N2ST000 1.3 0.1nH 500 10 500 10 16.61 0.20 0.13 400 MHQ0402PSA1N3BT000 1.3 0.2nH 500 10 500 10 16.61 0.20 0.13 400 MHQ0402PSA1N3CT000 1.3 0.3nH 500 10 500 10 16.61 0.20 0.13 400 MHQ0402PSA1N3ST000 1.4 0.1nH 500 10 500 10 16.22 0.30 0.18 400 MHQ0402PSA1N4BT000 1.4 0.2nH 500 10 500 10 16.22 0.30 0.18 400 MHQ0402PSA1N4CT000 1.4 0.3nH 500 10 500 10 16.22 0.30 0.18 400 MHQ0402PSA1N4ST000 1.5 0.1nH 500 10 500 10 14.74 0.20 0.15 400 MHQ0402PSA1N5BT000 1.5 0.2nH 500 10 500 10 14.74 0.20 0.15 400 MHQ0402PSA1N5CT000 1.5 0.3nH 500 10 500 10 14.74 0.20 0.15 400 MHQ0402PSA1N5ST000 Short bar residual inductance =0.11nH Measurement equipment Measurement item Product No. Manufacturer L, Q 4991A+16196D Keysight Technologies Self-resonant frequency 8720C Keysight Technologies DC resistance 4338A Yokogawa Equivalent measurement equipment may be used. Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use. (2/13) Please note that the contents may change without any prior notice due to reasons such as upgrading. 20181220 inductor_commercial_high-frequency_mhq0402psa_en.fm
