55PC0221-22-6/9CS2601 TE Connectivity

55PC0221 SPECIFICATION CONTROL DRAWING TITLE Date Revision TWO CONDUCTOR CABLE, UNSHIELDED, UNJACKETED, 600 VOLT 10-19-05 D This specification sheet forms a part of the latest issue of Raychem Specifiction 55PC. COMPONENT WIRES - 55PC0211 CONSTRUCTION DETAILS DIAMETER WEIGHT ( lb/1000 ft.) ( in.) CONDUCTOR PART NUMBER SIZE TARGET LOWER SPEC TARGET UPPER SPEC UPPER SPEC 1/ (AWG) LIMIT VALUE LIMIT VALUE LIMIT 55PC0221-24-* 24 .076 .079 .082 4.00 4.23 55PC0221-22-* 22 .088 .091 .094 5.87 6.12 55PC0221-20-* 20 .105 .108 .111 8.87 9.17 13.33 55PC0221-18-* 18 .124 .127 .130 13.82 55PC0221-16-* 16 .139 .142 .145 16.94 17.46 55PC0221-14-* 14 .168 .172 .176 26.07 26.78 55PC0221-12-* 12 .205 .209 .214 39.93 40.85 55PC0221-10-* 10 .252 .258 .264 62.99 64.65 115. 120. 55PC0221- 8-* 8 .376 .392 .406 CABLE RATINGS AND ADDITIONAL REQUIREMENTS PART NUMBER: TEMPERATURE RATING: 150C The in the part numbers above shall be replaced by Maximum continous conductor temperature VOLTAGE RATING: 600 volts (rms) at sea level a color code designator with a slash separating the component wire colors. INSULATION FLAWS: Impulse Dielectric Test, 8.0 kV (peak) 1/ Example: AWG 22, black and red component wires 55PC0221-22-0/2 Users should evaluate the suitability of this product for their application. Specifications are subject to change without notice. Tyco Electronics also reserves the right to make changes in materials or processing, which do not affect compliance with any specification, without notification to Buyer. 1/ COLORS AND COLOR CODE DESIGNATORS SHALL BE IN ACCORDANCE WITH MIL-STD-681. HOWEVER, DUE TO LENGTH LIMITATIONS OF THE RAYCHEM PART NUMBER, AN ALTERNATIVE COLOR CODE MAY REPLACE MIL-STD-681 COLOR CODE DESIGNATORS. (EXAMPLE: 901/902... MAY BE REPLACED BY Axxx.) OTHER CODES AND SUFFIXES MAY BE ADDED TO THE PART NUMBER, AS NECESSARY, TO CAPTURE ANY ADDITIONAL REQUIREMENTS IMPOSED BY THE PURCHASE ORDER. R Wire & Cable DIMENSIONS ARE IN INCHES AND, UNLESS OTHERWISE DESIGNATED, ARE NOMINAL 501 Oakside Avenue Redwood City, CA 94063-3800 Page 1 of 1 THIS SPECIFICATION SHEET TAKES PRECEDENCE OVER DOCUMENTS REFERENCED HEREIN. Phone: 1-800-227-8816 Fax: 1-650-361-6297 REFERENCED DOCUMENTS SHALL BE OF THE ISSUE IN EFFECT ON DATE OF INVITATION FOR BID. 2005 Tyco Electronics Corporation. All rights reserved.X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Multi-Conductor Cables category: Click to view products by TE Connectivity manufacturer: Other Similar products are found below : 8916-GRY-100 8917-BLK-100 8918-GRN/YEL-100 8920-BRN-1000 8920-RED-1000 89907-LT-DEC/GRY-500 CR3909-000 CR3927- 000 01342.35T.01 01364.35T.01 003201-000 CS2885-000 CS8782-000 CS9912-000 6200UE-NAT-U1000 CTC-0062-20-9/5-9 CTC-0062- 22-9/5-9 6304FE-877-U500 6309UE-877-1000 6320UE-NAT-U1000 644833-000 6502FE 8771000 6504UE-877-U1000 CW9530-000 CX6543-000 CXA-0066-20-4-9CS2973 CXA-0078-16-1-9CS2405 CXA-0078-22-4-9CS2405 CXA-0078-24-4-9CS2405 CXA-0140-16-6/9- 9CS2405 CY0660-000 706/2R-BLACK-EACH 720451-000 730859-000 MCC-USB-4-250 752687-000 768146-000 773159-000 7934A- BLK-1000 8125-CHR-100 8164-CHR-1000 820457-000 8205-CHR-1000 8240-BLK-U1000 82723-NAT-1000 82907-NAT-500 83003- YEL-500 83005-WHT-500 83006-DK-GRN-100 83008-WHT-1000
