TLP2304(E Toshiba

TLP2304 Photocouplers GaAAs Infrared LED & Photo IC TLP2304TLP2304TLP2304TLP2304 1. 1. ApplicationsApplications 1. 1. ApplicationsApplications Intelligent Power Module Signal Isolation Factory Automation (FA) Industrial Inverters 2. 2. 2. 2. GeneralGeneralGeneralGeneral The TLP2304 consists of a GaAAs light-emitting diode optically coupled with an integrated highgain, highspeed photodetector and is housed in the SO6 package. It supports operating temperatures of up to 125 . The photodetector has an internal Faraday shield that provides a guaranteed common-mode transient immunity of 20 kV/s. The TLP2304 guarantees minimum and maximum of propagation delay time, pulse width distortion. Therefore it is suitable for isolation interface between IPM and control IC circuits in motor control application. 3. 3. FeaturesFeatures 3. 3. FeaturesFeatures (1) Inverter logic type (open collector output) (2) Package: SO6 (3) Data transfer rate: 1 MBd (typ.) (NRZ) (4) Threshold input current: 5 mA (max) (5) Supply voltage: -0.5 to 30 V (6) Operating temperature: -40 to 125 (7) Supply current: 1.3 mA (max) (8) Common-mode transient immunity: 20 kV/s (min) (9) Isolation voltage: 3750 Vrms (min) (10) Safety standards UL-approved: UL1577, File No.E67349 cUL-approved: CSA Component Acceptance Service No.5A File No.E67349 (Note 1) VDE-approved: EN60747-5-5, EN62368-1 (Note 1)(Note 1)(Note 1) Option (V4) Note 1: When a VDE approved type is needed, please designate the Option (V4)Option (V4)Option (V4). 4. 4. 4. 4. Packaging and Pin AssignmentPackaging and Pin AssignmentPackaging and Pin AssignmentPackaging and Pin Assignment 1: Anode 3: Cathode 4: GND 5: V (Output) O 6: V CC 11-4L1S Start of commercial production 2018-09 2018 2018-09-04 1 Toshiba Electronic Devices & Storage Corporation Rev.1.0TLP2304 5. 5. 5. 5. Internal Circuit (Note)Internal Circuit (Note)Internal Circuit (Note)Internal Circuit (Note) Note: A 0.1-F bypass capacitor must be connected between pin 6 and pin 4. 6. 6. Principle of OperationPrinciple of Operation 6. 6. Principle of OperationPrinciple of Operation 6.1. 6.1. 6.1. 6.1. Truth TableTruth TableTruth TableTruth Table Input LED Output H ON L L OFF H 6.2. 6.2. Mechanical ParametersMechanical Parameters 6.2. 6.2. Mechanical ParametersMechanical Parameters Characteristics Dimension(Min) Unit Creepage distances 5.0 mm Clearance distances 5.0 Internal isolation thickness 0.4 2018 2018-09-04 2 Toshiba Electronic Devices & Storage Corporation Rev.1.0
