VS-45L(R), VS-150K(R), VS-150KS(R) Series www.vishay.com Vishay Semiconductors Standard Recovery Diodes (Stud Version), 150 A FEATURES Alloy diode High current carrying capability High surge current capabilities Stud cathode and stud anode version Designed and qualified for industrial level Material categorization: For definitions of compliance please see www.vishay.com/doc 99912 DO-205AA (DO-8) TYPICAL APPLICATIONS Battery chargers Welders PRODUCT SUMMARY Machine tool controls I 150 A F(AV) High power drives Package DO-205AA (DO-8) Medium traction applications Circuit configuration Single diode Freewheeling diodes MAJOR RATINGS AND CHARACTERISTICS PARAMETER TEST CONDITIONS VALUES UNITS 150 A I F(AV) T 150 C C I 235 A F(RMS) 50 Hz 3570 I A FSM 60 Hz 3740 50 Hz 64 2 2 I t kA s 60 Hz 58 V Range 100 to 600 V RRM T -40 to 200 C J ELECTRICAL SPECIFICATIONS VOLTAGE RATINGS V , MAXIMUM REPETITIVE V , MAXIMUM NON-REPETITIVE I MAXIMUM RRM RSM RRM VOLTAGE TYPE NUMBER PEAK REVERSE VOLTAGE PEAK REVERSE VOLTAGE AT T = 175 C J CODE V V mA 10 100 200 20 200 300 VS-45L(R) VS-150K(R) 30 300 400 35 VS-150KS(R) 40 400 500 60 600 720 Revision: 25-Nov-13 Document Number: 93489 1 For technical questions within your region: DiodesAmericas vishay.com, DiodesAsia vishay.com, DiodesEurope vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000VS-45L(R), VS-150K(R), VS-150KS(R) Series www.vishay.com Vishay Semiconductors FORWARD CONDUCTION PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS 150 A Maximum average forward current I 180 conduction, half sine wave F(AV) at case temperature 150 C Maximum RMS forward current I DC at 142 C case temperature 235 F(RMS) t = 10 ms 3570 No voltage reapplied t = 8.3 ms 3740 A Maximum peak, one cycle forward, I FSM non-repetitive surge current t = 10 ms 3000 100 % V RRM reapplied t = 8.3 ms 3140 Sinusoidal half wave, initial T = T maximum J J t = 10 ms 64 No voltage reapplied t = 8.3 ms 58 2 2 2 Maximum I t for fusing I t kA s t = 10 ms 45 100 % V RRM reapplied t = 8.3 ms 41 2 2 2 Maximum I t for fusing I t t = 0.1 to 10 ms, no voltage reapplied 640 kA s Low level value of threshold voltage V (16.7 % x x I < I < x I ), T = T maximum 0.67 F(TO)1 F(AV) F(AV) J J V High level value of threshold voltage V (I > x I ), T = T maximum 0.83 F(TO)2 F(AV) J J Low level value of forward r (16.7 % x x I < I < x I ), T = T maximum 1.42 f1 F(AV) F(AV) J J slope resistance mW High level value of forward r (I > x I ), T = T maximum 0.91 f2 F(AV) J J slope resistance Maximum forward voltage drop V I = 471 A, T = 25 C, t = 10 ms sinusoidal wave 1.33 V FM pk J p THERMAL AND MECHANICAL SPECIFICATIONS PARAMETER SYMBOL TEST CONDITIONS VALUESUNITS Maximum junction operating T , T -40 to 200 C J Stg and storage temperature range Maximum thermal resistance, R DC operation 0.25 thJC junction to case K/W Maximum thermal resistance, R Mounting surface, smooth, flat and greased 0.10 thCS case to heatsink minimum 14.1 (125) Not lubricated threads maximum 17.0 (150) Mounting torque N m 45L (lbf in) minimum 12.2 (108) Lubricated threads maximum 15.0 (132) minimum 11.3 (100) Not lubricated threads Mounting torque maximum 14.1 (125) N m 150K (lbf in) minimum 9.5 (85) 150KS Lubricated threads maximum 12.5 (110) 100 g Approximate weight 3.5 oz. 45L DO-205AC (DO-30) Case style 150K-A See dimensions - link at the end of datasheet DO-205AA (DO-8) 150KS B-42 Revision: 25-Nov-13 Document Number: 93489 2 For technical questions within your region: DiodesAmericas vishay.com, DiodesAsia vishay.com, DiodesEurope vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
