L016N004AYYHET0000 Vishay

LCD-016N004A Vishay 16 x 4 Character LCD FEATURES Type: Character Display format: 16 x 4 characters Built-in controller: KS 0066 (or equivalent) Duty cycle: 1/16 5 x 8 dots includes cursor + 5 V power supply (also available for + 3 V) LED can be driven by pin 1, pin 2, pin 15, pin 16 or A and K N.V. optional for 3 V power supply Compliant to RoHS directive 2002/95/EC MECHANICAL DATA ABSOLUTE MAXIMUM RATINGS ITEM STANDARD VALUE UNIT STANDARD VALUE ITEM SYMBOL UNIT Module Dimension 87.0 x 60.0 MIN. TYP. MAX. Viewing Area 62.0 x 26.0 Power Supply V to V - 0.3 - 7.0 DD SS V Dot Size 0.55 x 0.55 Input Voltage V - 0.3 - V I DD mm Dot Pitch 0.60 x 0.60 Note Mounting Hole 82.0 x 55.0 V = 0 V, V = 5.0 V SS DD Character Size 2.95 x 4.75 ELECTRICAL CHARACTERISTICS STANDARD VALUE ITEM SYMBOL CONDITION UNIT MIN. TYP. MAX. V = + 5 V 4.7 5.0 5.3 V DD Input Voltage V DD V = + 3 V 2.7 3.0 5.3 V DD Supply Current I V = + 5 V - 1.0 1.2 mA DD DD - 20 C 5.0 5.1 5.7 0 C 4.6 4.8 5.2 Recommended LC Driving Voltage for Normal Temperature V to V 25 C 4.1 4.5 4.7 V DD 0 Version Module 50 C 3.9 4.2 4.5 70 C 3.7 3.9 4.3 LED Forward Voltage V 25 C - 4.2 4.6 V F LED Forward Current I 25 C - 220 440 mA F EL Power Supply Current I V = 110 V , 400 Hz - - 5.0 mA EL EL AC OPTIONS PROCESS COLOR BACKLIGHT STN STN STN FSTN STN TN None LED EL CCFL Gray Yellow Blue B&W Color xxxx xxx For detailed information, please see the Product Numbering System document. DISPLAY CHARACTER ADDRESS CODE Display Position 12345 6789 10 11 12 13 14 15 16 DD RAM Address 0001020304 0506070809 0A 0B 0C 0D 0E 0F DD RAM Address 4041424344 4546474849 4A 4B 4C 4D 4E 4F DD RAM Address 1011121314 1516171819 1A 1B 1C 1D 1E 1F DD RAM Address 5051525354 5556575859 5A 5B 5C 5D 5E 5F Document Number: 37305 For technical questions, contact: displays vishay.com www.vishay.com Revision: 30-Oct-08 1 LCD-016N004A 16 x 4 Character LCD Vishay INTERFACE PIN FUNCTION PIN NO. SYMBOL FUNCTION 1V Ground SS 2V Power supply (+ 3 V or + 5 V) DD 3V Contrast adjustment 0 4 RS H/L register select signal 5R/W H/L read/write signal 6E H L enable signal 7 DB0 H/L data bus line 8 DB1 H/L data bus line 9 DB2 H/L data bus line 10 DB3 H/L data bus line 11 DB4 H/L data bus line 12 DB5 H/L data bus line 13 DB6 H/L data bus line 14 DB7 H/L data bus line 15 A/V + 4.2 V for LED (RA = 0 )/negative voltage output EE 16 K Power supply for B/L (0 V) DIMENSIONS in millimeters 87.0 0.5 10.0 38.1 (P2.54 x 15) 13.6 Max. 10.0 Max. 2.5 2.0 16 x 1.0 9.0 5.2 1 A K 4 x 1.0 PTH 0 1.6 1.6 4 x 2.5 PTH 2.5 82.0 4 x 5.0 PAD 15.4 56.2 (AA) LED B/L EL or NO B/L 12.5 62.0 (VA) 3.55 4.0 79.0 2.95 0.60 0.55 Dot Size www.vishay.com For technical questions, contact: displays vishay.com Document Number: 37305 2 Revision: 30-Oct-08 60.0 0.5 37.4 11.3 26.0 (VA) 17 20.8 (AA) 19.6 55.0 2.5 2.5 5.35 7.0 26.5 4.75 15.0 22.5 0.60 0.55
