857-401 JUMPFLEX Transducers 3 Isolation amplifier, configurable with digital output 196 IN+ 1 5 OUT+ IN OUT U,I U,I GND 1 2 6 GND 2 DO 3 7 Us+ DO POWER GND 3 4 8 GND 3 > < 94 mm/3.68 in > 6 mm/0.23 in Short description: The device is supplied with 24VDC, which can be commoned using lateral The software-configurable 857-401 Isolation Amplifier is used to convert, am- push-in type jumper bars in a quick and cost effective way. A green LED on the plify, filter and electrically isolate analog standard signals. The device has a 3- front panel indicates normal operation. The isolation amplifier meets the re- way isolation with a 2.5kV test voltage. DIP switches accessible from the side quirements for safe isolation of input, output and supply circuits with 2.5kV test can be used to configure the signals in both input and output. voltage according to EN 61140. In addition to standard signals, bipolar ( 10V, 20mA) and 0 to 30V signals can also be set on the input side. The analog output supports standard unipolar signals. In addition, the devices can be configured using FDT/DTM software. The software offers additional setting options such as special input and output signal combinations with intermediate values or inversion of the analog output. Measurement range switching is calibrated. A digital switching output is avai- lable that can also be configured using software. Pack. Description Item No. Technical Data Unit Isolation amplifier, configurable 857-401 1 Configuration DIP switch or configuration software with digital output Input signal -10 ... +10 V, -20 ... +20 mA, 0 ... +30 V Max. input signal (31.2 V (U ) 100 mA (I ) IN IN Input resistance 200 (I input) > 100 k (U input) Accessories Output signal 0 ... 20 mA, 4 ... 20 mA, Configuration software - 759-370 FDT Frame Application 0 ... 10 V, 2 ... 10 V, 0... 5 V, 1 ... 5 V, - DTM (Device Tool Manager) 0 ... 10 mA, 2 ... 10 mA Download: see www.wago.com Load impedance 600 (I output) WAGO USB Service Cable 750-923 2 k (U output) General accessories see pages 222 - 223 Step response 8 ms Voltage supply V 24 V DC N Supply voltage range 16.8 V ... 31.2 V Current input at 24 V DC < 40 mA Transmission error < 0.1 % of upper range value Approvals Temperature coefficient 0.01 % /K Shipbuilding g (pending) Min. measuring span 1 V, 2 mA (configurable) 4 r ANSI/ISA 12.12.01 Class I Div2 ABCD T4 Output - Digital Conformity marking 1 Max. switching voltage Supply voltage applied Max. continuous current 500 mA (up to 60 C) 100 mA (60 C ... 70 C) General Specifications Test voltage Dimensions (mm) W x H x L 6 x 96 x 94 (input/output/supply) 2.5 kV AC, 50 Hz, 1 min. Height from upper-edge of DIN 35 rail Ambient operating temperature -25 C ... +70 C Wire connection CAGE CLAMP S Storage temperature -40 C ... +85 C Cross sections solid: 0.08 mm ... 2.5 mm / AWG 28 ... 12 fine-stranded: 0.34 mm ... 2.5 mm / AWG 22 ... 12 Stripped lengths 9 ... 10 mm / 0.37 in WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 - D-32385 Minden Phone: +49(0)571/887-0 E-Mail: info wago.com Subject to design changes 22.04.2010 Hansastr. 27 - D-32423 Minden Fax: +49(0)571/887-169 www.wago.com < 96 mm/3.76 in > >DIP Switch Adjustability 857-401 = ON Input Signal Start Value End Value DIP S1 DIP S1 DIP S2 DIP S1 DIP S2 1 234567 V mA 234567 V mA 89 10 123 V mA 8 9 10 123 V mA Voltage 0 0 5.5 11 10 20 5.5 11 Current -10 -20 6 12 -10 -20 6 12 -9.5 -19 6.5 13 -9.5 -19 6.5 13 -9 -18 7 14 -9 -18 7 14 -8.5 -17 7.5 15 -8.5 -17 7.5 15 -8 -16 8 16 -8 -16 8 16 -7.5 -15 8.5 17 -7.5 -15 8.5 17 -7 -14 9 18 -7 -14 9 18 -6.5 -13 9.5 19 -6.5 -13 9.5 19 3 -6 -12 10 20 -6 -12 10 20 -5.5 -11 10.5 -5.5 -11 10.5 -5 -10 11 -5 -10 11 -4.5 -9 11.5 -4.5 -9 11.5 -4-8 12 -4-8 12 -3.5 -7 13 -3.5 -7 13 -3 -6 14 -3 -6 14 -2.5 -5 15 -2.5 -5 15 -2 -4 16 -2 -4 16 -1.5 -3 17 -1.5 -3 17 -1 -2 18 -1 -2 18 -0.5 -1 19 -0.5 -1 19 0020 0020 0.5 1 21 0.5 1 21 1 2 22 1 2 22 1.5 3 23 1.5 3 23 2 4 24 2 4 24 2.5 5 25 2.5 5 25 3 6 26 3 6 26 3.5 7 27 3.5 7 27 4 8 28 4 8 28 4.5 9 29 4.5 9 29 5 10 30 5 10 30 Measuring Range Overow/ Default Settings Output Signal Range DO Measuring Range Measuring Range Measuring Range Underow Overow Underow In delivery status all DIP switches are in the position OFF. 456 78 9 10 Signalisation* 0 20 mA DO Us+ switched not active Input Upper limit of output range Lower limit of output range +2.5% -5% 4 20 mA DO GND switched active - Input signal: Voltage 0 10 mA - Start value: 0 V Upper limit of output range Lower limit of output range +2.5% - End value: 10 V 2 10 mA Output 0 10 V Upper limit of output range Lower limit of output range - Output signal: Current 2 10 V - Start value: 0 mA 0 5 V Upper limit of output range Lower limit of output range - End value: 20 mA 1 5 V - Measuring range underow: 0 mA * related to input signal - Measuring range overow: 20.5 mA Digital output - not active WAGO Kontakttechnik GmbH & Co. KG Postfach 2880 - D-32385 Minden Phone: +49(0)571/887-0 E-Mail: info wago.com Subject to design changes 22.04.2010 Hansastr. 27 - D-32423 Minden Fax: +49(0)571/887-169 www.wago.com
