11-03-0016 Waldom

3.96mm (.156 ) Pitch FEATURES AND SPECIFICATIONS Features and Benets Electrical KK n Crimp wire sizes 18 to 26 AWG Voltage: 250V Single-Sided Terminals n Patented double cantilever design Current: Use table n Complete line of terminal crimping equipment available AWG 18 20 22 24 26 Phosphor Bronze n 2878 bifurcated terminal offers 2 points of contact for 7.00 6.25 5.50 5.00 4.50 (Amperes max.) 2478/2578/2878 increased reliability Brass 5.00 4.75 4.50 4.25 4.00 (Amperes max.) Reference Information Contact Resistance: 20mW max. Packaging: Bag or reel Dielectric Withstanding Voltage: 1500V UL File No.: E29179 Insulation Resistance: 50,000 MW min. CSA File No.: LR19980 Use With: 2574 housing Mechanical Designed In: Inches Contact Insertion Force: 1.36kg (3 lb) max. Contact Retention to Housing: 3.63kg (8 lb) min. E when pulled in an axial direction Normal Force: 0.75kg (1.65 lb) Physical Contact: Brass/Phosphor Bronze Plating: See Table Temperature: 0 to +50C Note: 2478 shown ORDERING INFORMATION AND DIMENSIONS Tin Plating Gold Plating No. 1 Gold Plating No. 2 Maximum Insulation Wire Size Series Material Outside Diameter Bag Reel Bag Reel Bag Reel 18-20 2.79 (.110) 2478 Phosphor Bronze 08-52-0072 08-52-0071 08-58-0122 08-58-0121 08-65-0115 08-65-0114 18-20 2.79 (.110) 2478 Brass 08-50-0106 08-50-0105 08-56-0106 08-56-0105 08-55-0104 08-55-0103 18-20 2.79 (.110) 2878 Phosphor Bronze 08-52-0127 08-52-0126 08-58-0128 08-58-0127 08-65-0119 08-65-0118 18-20 2.79 (.110) 2878 Brass 08-50-0116 08-50-0115 22-26 1.65 (.065) 2578 Phosphor Bronze 08-50-0134 08-50-0133 08-58-0126 08-58-0125 08-65-0117 08-65-0116 22-26 1.65 (.065) 2578 Brass 08-50-0108 08-50-0107 08-56-0108 08-56-0107 08-55-0106 08-55-0105 Hand Tools Crimp Machine Terminal Engineering No. Crimping Order and Engineering No. Extraction Order and Engineering No. Bench Order and Engineering No. Automatic Type (JHTR-2445-A) (HTA-2174) (TM-40D) 2478 11-04-0418 2578(a) 11-01-0026 11-03-0016 11-04-0420 KM40S 2878 11-04-0418 US Standard Product, available through Molex franchised distributors Recommended wire range assumes stranded wire Plating No. 1: 20m min. Gold in contact area with a ash overall Plating No. 2: 15m min. Gold in contact area only E-68 990 Sockets and Edge ConnectorsX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for waldom manufacturer: Other Similar products are found below : 60286 F-501 F-596-C 76650-0030 1625-9PRT F-024-C F-041 F-465 F-533 F-630 CCB-2-C CW-8-C K-176 WMLX-202 W-HT-2285-P 60041C 7180-2 T-159 T-152 T-151-C CCB-7-P CCB-10-P CCB-11-P CCB-13-P CCB-14-P CW-6-C F-048-C KCW-6 A-104 F-035-C F-051 F-056-C F-465-C F-524-C F-526 F-527-C KF-526 WA-4100D F-017-C F-029-C F-040-C F-517-C F-528-C FN-825-C 614-1 630 76650-0040 K-180 K60056 HD-4211
