DISCRETE SEMICONDUCTORS DDATA SHEET BT300S series Thyristors Product specification September 1997 Semiconductors Product specification Thyristors BT300S series BT300M series GENERAL DESCRIPTION QUICK REFERENCE DATA Glasspassivated thyristors ina plastic SYMBOL PARAMETER MAX. MAX. MAX. UNIT envelope, suitable for surface mounting, intended for use in BT300S (or BT300M)- 500R 600R 800R applications requiring high V , Repetitive peak off-state 500 600 800 V DRM bidirectional blocking voltage V voltages RRM capability and high thermal cycling I Average on-state current 5 5 5 A T(AV) performance. Typical applications I RMS on-state current 8 8 8 A T(RMS) include motor control, industrial and I Non-repetitive peak on-state 65 65 65 A TSM domestic lighting, heating and static current switching. PINNING - SOT428 PIN CONFIGURATION SYMBOL PIN Standard Alternative tab NUMBER S M ak 1 cathode gate 2 anode anode 3 gate cathode 2 g 1 3 tab anode anode LIMITING VALUES Limiting values in accordance with the Absolute Maximum System (IEC 134). SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT -500R -600R -800R 1 1 V , V Repetitive peak off-state - 500 600 800 V DRM RRM voltages I Average on-state current half sine wave T 107 C - 5 A T(AV) mb I RMS on-state current all conduction angles - 8 A T(RMS) I Non-repetitive peak half sine wave T = 25 C prior to TSM j on-state current surge t = 10 ms - 65 A t = 8.3 ms - 71 A 2 2 2 ItI t for fusing t = 10 ms - 21 A s dI /dt Repetitive rate of rise of I = 10 A I = 50 mA - 50 A/s T TM G on-state current after dI /dt = 50 mA/s G triggering I Peak gate current - 2 A GM V Peak gate voltage - 5 V GM V Peak reverse gate voltage - 5 V RGM P Peak gate power - 5 W GM P Average gate power over any 20 ms period - 0.5 W G(AV) T Storage temperature -40 150 C stg T Operating junction - 125 C j temperature 1 Although not recommended, off-state voltages up to 800V may be applied without damage, but the thyristor may switch to the on-state. The rate of rise of current should not exceed 15 A/s. September 1997 1 Rev 1.100
