AOZ8802A Ultra-Low Capacitance TVS Diode Array General Description Features The AOZ8802A is a transient voltage suppressor array z ESD protection for high-speed data lines: designed to protect high speed data lines such as HDMI, IEC 61000-4-2, level 4 (ESD) immunity test MDDI, USB, SATA, and Gigabit Ethernet from damaging Air discharge: 15kV Contact discharge: 15kV ESD events. IEC61000-4-4 (EFT) 40A (5/50nS) IEC61000-4-5 (Lightning) 2.5A (8/20S) This device incorporates four surge rated, low capacitance steering diodes and a TVS in a single Human Body Model (HBM) 24kV package. During transient conditions, the steering diodes z Array of surge rated diodes with internal TVS diode direct the transient to either the positive side of the power z Small package saves board space supply line or to ground. z Protects two I/O lines The AOZ8802A provides a typical line to line capacitance z Low capacitance between I/O lines: 0.3pF of 0.3pF and low insertion loss up to 6GHz providing z Low clamping voltage greater signal integrity making it ideally suited for HDMI z Low operating voltage: 5.0V 1.3 applications, such as Digital TVs, DVD players, set-top boxes and USB applications in mobile Applications computing devices. z USB, MDDI, SATA ports The AOZ8802A comes in a RoHS compliant and Halogen z Monitors and flat panel displays Free 1.6mm x 1.0mm x 0.55mm DFN-6 package and is z Set-top box rated -40C to +85C junction temperature range. z Video graphics cards z Digital Video Interface (DVI) z Notebook computers Typical Application Vbus +5V D+ D+ USB 2.0 USB 2.0 Controller Port D- D- GND AOZ8802A Figure 1. USB Port Rev. 1.0 October 2010 www.aosmd.com Page 1 of 9 AOZ8802A Ordering Information Part Number Ambient Temperature Range Package Environmental AOZ8802ADI -40C to +85C DFN-6 Green Product RoHS Compliant AOS Green Products use reduced levels of Halogens, and are also RoHS compliant. Please visit www.aosmd.com/web/quality/rohs compliant.jsp for additional information. Pin Configuration CH1 1 NC 6 CH2 2 NC 5 3 VN VN 4 DFN-6 (Top View) Absolute Maximum Ratings Exceeding the Absolute Maximum ratings may damage the device. Parameter Rating Storage Temperature (T ) -65C to +150C S (1) ESD Rating per IEC61000-4-2, contact 15kV (1) ESD Rating per IEC61000-4-2, air 15kV (2) ESD Rating per Human Body Model 24kV Notes: 1. IEC 61000-4-2 discharge with C = 150pF, R = 330 . Discharge Discharge 2. Human Body Discharge per MIL-STD-883, Method 3015 C = 100pF, R = 1.5k. Discharge Discharge Maximum Operating Ratings Parameter Rating Junction Temperature (T ) -40C to +125C J Rev. 1.0 October 2010 www.aosmd.com Page 2 of 9
