JIANGSU CHANGJING ELECTRONICS TECHNOLOGY CO., LTD DFN1006-3L Plastic-Encapsulate MOSFETs CJBA7002K N-Channel MOSFET V R I (BR)DSS DS(on)MAX D DFN1006-3L 1.5 10V 60V 0.41A 1.8 4.5V FEATURE APPLICATION Low On-Resistance Load Switch Low Threshold Voltage Portable Applications Fast Switching Speed Power Management Functions ESD Protected Gate MARKING: Equivalent Circuit ABSOLUTE MAXIMUM RATINGS (T =25 unless otherwise noted) a Parameter Symbol Value Unit Drain-Source Voltage V 60 V DS Gate-Source Voltage V 20 V GS T =25 0.41 a Continuous Drain Current I A D T =85 0.30 a Pulsed Drain Current I 1.2 A DM Power Dissipation PD 0.1 W Thermal Resistance from Junction to Ambient R 1250 /W JA Storage Temperature TSTG -55~ +150 Rev. - 1.0 www.jscj-elec.com 1 MOSFET ELECTRICAL CHARACTERISTICS MOSFET ELECTRICAL CHARACTERISTICS(T =25 unless otherwise noted) a Parameter Symbol Test Condition Min Type Max Unit Static Characteristics Drain-source breakdown voltage V(BR)DSS VGS = 0V, ID =250A 60 V Zero gate voltage drain current I V =60V,V = 0V 100 nA DSS DS GS V =20V, V = 0V 10 GS DS Gate-body leakage current I A GSS V =5V, V = 0V 1 GS DS Gate threshold voltage V V =V , I =250A 1.3 1.4 2.3 V GS(th) DS GS D V =10V, I =40mA 1.2 1.5 GS D a Drain-source on-resistance RDS(on) V =4.5V, I =35mA 1.3 1.8 GS D a Forward tranconductance gfs V = 5V, I = 40mA 100 mS DS D Diode forward voltage V V =0V, I =300mA 0.84 1.1 V SD DS S Dynamic characteristics b Input Capacitance C 41 80 iss b Output Capacitance C V =40V,V =0V,f =1MHz 3.6 7 pF oss DS GS b Reverse Transfer Capacitance C 2.9 5.6 rss Gate resistance R V = 0V, V = 0V, f = 1MHz 81 200 g DS GS VGS =4.5V 0.72 1.5 Total Gate Charge Q g 1.41 2.8 V = 50V, I = 1A nC DS D Gate-Source Charge Q V =10V 0.24 0.4 gs GS Gate-Drain Charge Q 0.24 0.5 gd b Turn-on delay time t 3.98 10 d(on) b Turn-on rise time t 4.95 10 r V =50V,I =1A, DS D ns b V =10V,RG=6 Turn-off delay time t GS 18.52 40 d(off) b Turn-off fall time t 11.94 25 f Notes: a. Pulse Test : Pulse width300s, duty cycle 2%. b. These parameters have no way to verify. Rev. - 1.0 www.jscj-elec.com 2
