IS61/64WV102416DALL IS61/64WV102416DBLL AUGUST 2019 1Mx16 HIGH-SPEED ASYNCHRONOUS CMOS STATIC RAM WITH 3.3V/1.8V SUPPLY FEATURES DESCRIPTION The ISSI IS61/64WV102416DALL/BLL are high-speed, 16M High-speed access time: 10ns, 12ns bit static RAMs organized as 1024K words by 16 bits. It is High- performance, low power CMOS process fabricated using ISSI s high-performance CMOS technology. Multiple center power and ground pins for greater noise immunity This highly reliable process coupled with innovative circuit Easy memory expansion with CS and OE design techniques, yields high-performance and low power TTL compatible inputs and outputs consumption devices. Single power supply When CS is HIGH (deselected), the device assumes a 1.65V-2.2V VDD (IS61/64WV102416DALL) standby mode at which the power dissipation can be reduced 2.4V-3.6V VDD (IS61/64WV102416DBLL) down with CMOS input levels. Easy memory expansion is Packages available : provided by using Chip Enable and Output Enable inputs. - 48 ball mini BGA (6mm x 8mm) The active LOW Write Enable (WE ) controls both writing - 48 pin TSOP (Type I) and reading of the memory. Industrial and Automotive temperature support A data byte allows Upper Byte (UB ) and Lower Byte (LB ) Lead-free available access. Data Control for upper and lower bytes The device is packaged in the JEDEC standard 48-Pin TSOP (TYPE I) and 48-pin mini BGA (6mm x 8mm). FUNCTIONAL BLOCK DIAGRAM 1024K x 16 MEMORY DECODER A0 A19 ARRAY VDD GND I/O0 I/O7 I/O DATA COLUMN I/O CIRCUIT I/O8 I/O15 CS CONTROL OE CIRCUIT WE UB LB Copyright 2019 Integrated Silicon Solution, Inc. All rights reserved. ISSI reserves the right to make changes to this specification and its products at any time without notice. ISSI assumes no liability arising out of the application or use of any information, products or services described herein. Customers are advised to obtain the latest version of this device specification before relying on any published information and before placing orders for products. Integrated Silicon Solution, Inc. does not recommend the use of any of its products in life support applications where the failure or malfunction of the product can reasonably be expected to cause failure of the life support system or to significantly affect its safety or effectiveness. Products are not authorized for use in such applications unless Integrated Silicon Solution, Inc. receives written assurance to its satisfaction, that: a.) the risk of injury or damage has been minimized b.) the user assume all such risks and c.) potential liability of Integrated Silicon Solution, Inc is adequately protected under the circumstances Integrated Silicon Solution, Inc.- www.issi.com 1 Rev. A2 08/07/2019 IS61/64WV102416DALL IS61/64WV102416DBLL PIN CONFIGURATIONS 48-Pin mini BGA (6mm x 8mm) 48-Pin TSOP ,TYPE I ( 12mm x 20mm ) 1 2 3 4 5 6 1 48 A5 A4 2 47 A6 A3 3 A2 46 A7 A LB OE A0 A1 A2 NC 4 A8 A1 45 OE A0 5 44 43 NC 6 UB B 7 42 LB CS I/O8 UB A3 A4 CE I/O0 I/O15 I/O0 8 41 I/O1 9 40 I/O14 I/O2 10 39 I/O13 I/O9 I/O10 A5 A6 I/O1 I/O2 I/O12 C I/O3 11 38 37 VSS VDD 12 VDD VSS 13 36 I/O4 14 35 I/O11 D VSS I/O11 A17 A7 I/O3 VDD I/O5 15 34 I/O10 33 I/O9 I/O6 16 I/O7 17 32 I/O8 31 WE 18 NC E VDD I/O12 NC A16 I/O4 VSS 30 NC 19 A9 A19 20 29 A10 21 A11 A18 28 A12 A17 22 27 F I/O14 I/O13 A14 A15 I/O5 I/O6 A16 23 26 A13 A15 24 25 A14 G I/O15 A19 A12 A13 WE I/O7 H A18 A8 A9 A10 A11 NC PIN DESCRIPTIONS A0-A19 Address Inputs I/O0-I/O15 Data Inputs/Outputs CS Chip Enable Input OE Output Enable Input WE Write Enable Input LB Lower-byte Control (I/O0-I/O7) UB Upper-byte Control (I/O8-I/O15) NC No Connection VDD Power VSS Ground Integrated Silicon Solution, Inc.- www.issi.com 2 Rev. A2 08/07/2019
