LCD-016N002P www.vishay.com Vishay 16 x 2 Character LCD FEATURES Type: Character Display format: 16 x 2 characters Built-in controller: ST 7066 (or equivalent) Duty cycle: 1/16 5 x 8 dots includes cursor + 5 V power supply Optional: Smaller character size (2.95 mm x 4.35 mm) Material categorization: For definitions of compliance please see www.vishay.com/doc 99912 MECHANICAL DATA ABSOLUTE MAXIMUM RATINGS ITEM STANDARD VALUE UNIT STANDARD VALUE ITEM SYMBOL UNIT Module Dimension 85.0 x 25.2 MIN. TYP. MAX. Viewing Area 66.0 x 16.0 Power Supply V to V - 0.3 - 7.0 DD SS V Dot Size 0.55 x 0.65 Input Voltage V - 0.3 - V I DD mm Dot Pitch 0.60 x 0.70 Note V = 0 V, V = 5.0 V Mounting Hole 80.5 x 22.0 SS DD Character Size 2.95 x 5.55 ELECTRICAL CHARACTERISTICS STANDARD VALUE ITEM SYMBOL CONDITION UNIT MIN. TYP. MAX. Input Voltage V V = + 5 V 4.7 5.0 5.3 V DD DD Supply Current I V = + 5 V -1.2 1.5 mA DD DD - 20 C - - 5.2 0 C - - 4.2 Recommended LC Driving Voltage for Normal Temperature V to V 25 C - 3.8 - V DD 0 Version Module 50 C 3.5 - - 70 C 3.2 - - LED Forward Voltage V 25 C - 4.2 4.6 V F LED Forward Current - Array - 100 - I 25 C mA F LED Forward Current - Edge - 20 40 EL Power Supply Current I V = 110 V , 400 Hz -- 5.0 mA EL EL AC OPTIONS PROCESS COLOR BACKLIGHT STN STN STN FSTN STN TN None LED EL CCFL Gray Yellow Blue B&W Color xxxx x xxx For detailed information, please see the Product Numbering System document. Revision: 05-Oct-12 Document Number: 37302 1 For technical questions, contact: displays vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000LCD-016N002P www.vishay.com Vishay DISPLAY CHARACTER ADDRESS CODE Display Position 123456 789 10 11 12 13 14 15 16 DD RAM Address 00 010203040506 070809 0A 0B 0C 0D 0E 0F DD RAM Address 40 414243444546 474849 4A 4B 4C 4D 4E 4F INTERFACE PIN FUNCTION PIN NO. SYMBOL FUNCTION 1 DB7 H/L data bus line 2 DB6 H/L data bus line 3 DB5 H/L data bus line 4 DB4 H/L data bus line 5 DB3 H/L data bus line 6 DB2 H/L data bus line 7 DB1 H/L data bus line 8 DB0 H/L data bus line 9E H L enable signal 10 R/W H/L read/write signal 11 RS H/L register select signal 12 V Contrast adjustment 0 13 V Ground SS 14 V Power supply (+ 5 V) DD DIMENSIONS in millimeters 85.0 0.5 80.5 71.2 H1 Max. 3 66.0 (VA) H2 4.4 56.21 (AA) 12 13 14 1.5 1.6 4 x R1.25 1.7 3.55 2.95 0.6 0.6 2.54 0.55 12 14 x 1.0 PTH 14 x 1.8 PAD LED - H/L B/L High H1 13.2 H2 8.6 13 14 Pin Detail Dot Size Revision: 05-Oct-12 Document Number: 37302 2 For technical questions, contact: displays vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 25.2 0.05 22 1.5 16 (VA) 11.5 (AA) 3.4 19 1.7 3 8 (P2.54 x 6) 15.24 18 22 5.95 0.4 5.55 0.7 0.65
