VO2223 www.vishay.com Vishay Semiconductors Optocoupler, Power Phototriac FEATURES Maximum trigger current (I ): 10 mA FT 8 1 Isolation test voltage 5300 V RMS 2 Peak off-state voltage 600 V Load current 0.9 A 6 RMS 3 dV/dt of 210 V/s 5 4 DIP-8 package 21081-4 V Pure tin leads DE 2317123171 Material categorization: for definitions of compliance please see www.vishay.com/doc 99912 APPLICATIONS PIN FUNCTION 1LED cathode Home appliances (air conditioners, microwave ovens, washing machines, personal hygiene systems, 2LED anode refrigerators, fan heaters, inductive heating cooker, water 3LED cathode heaters, etc.) 4LED cathode Industrial equipments 5Triac gate 6Triac T1 AGENCY APPROVALS 8Triac T2 The safety application model number covering all products in this data sheet is VO2223. This model number should be DESCRIPTION used when consulting safety agency documents. The VO2223 is an optically couple phototriac driving a UL / cUL 1577 power triac in a DIP-8 package. It provides a 5300 V of input DIN EN 60747-5-5 (VDE 0884-5), available with option 1 to output isolation. ORDERING INFORMATION DIP- V O 2223 - X 00 PART NUMBER PACKAGE OPTION 7.62 mm AGENCY CERTIFIED / PACKAGE TRIGGER, CURRENT I (mA) FT UL, cUL 10 DIP-8 VO2223 UL, cUL, VDE (option 1) 10 DIP-8 VO2223-X001 Rev. 1.5, 18-Mar-2021 Document Number: 81166 1 For technical questions, contact: optocoupleranswers vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 VO2223 www.vishay.com Vishay Semiconductors ABSOLUTE MAXIMUM RATINGS (T = 25 C, unless otherwise specified) amb PARAMETER TEST CONDITION SYMBOL VALUE UNIT INPUT LED continuous forward current I 50 mA F LED reverse voltage V 6V R OUTPUT Repetitive peak off-state voltage Sine wave, 50 Hz to 60 Hz, gate open V 600 V DRM On-state RMS current I 0.9 A T(RMS) Peak non-repetitive surge current (60 Hz, 1 cycle) I 9A TSM COUPLER (2) Total power dissipation P 1.2 W diss Ambient temperature range T -40 to +85 C amb Storage temperature range T -40 to +125 C stg (1) Soldering temperature t 10 s max. T 260 C sld Isolation test voltage For 1 s V 5300 V ISO RMS Notes Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. Functional operation of the device is not implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute maximum ratings for extended periods of the time can adversely affect reliability (1) Refer to wave profile for soldering conditions for through hole devices (2) Total power dissipation value is based on 2S2P PCB ABSOLUTE MAXIMUM RATING CURVES 80 1.0 0.9 0.8 60 0.7 0.6 40 0.5 0.4 0.3 20 0.2 0.1 0 0 -40 -20 0 20 40 60 80 100 120 -40 10 60 110 21296 T - Ambient Temperature (C) Ambient Temperature (C) amb Fig. 1 - Power Dissipation vs. Temperature Fig. 2 - Allowable Load Current vs. Ambient Temperature Note The allowable load current was calculated out under a given operating conditions and only for reference: LED power: Q = 0.015 W, (4-layer) = 35 C/W E BA Rev. 1.5, 18-Mar-2021 Document Number: 81166 2 For technical questions, contact: optocoupleranswers vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000 P - Input Power Disspation (mW) diss Load Current (A)
