Please note that Cypress is an Infineon Technologies Company. The document following this cover page is marked as Cypress document as this is the company that originally developed the product. Please note that Infineon will continue to offer the product to new and existing customers as part of the Infineon product portfolio. Continuity of document content The fact that Infineon offers the following product as part of the Infineon product portfolio does not lead to any changes to this document. Future revisions will occur when appropriate, and any changes will be set out on the document history page. Continuity of ordering part numbers Infineon continues to support existing part numbers. Please continue to use the ordering part numbers listed in the datasheet for ordering. www.infineon.comCY7C65210/CY7C65217 CY7C65210A/CY7C65217A USB Billboard Controller USB Billboard Controller USB Suspend mode for low power Features Operating voltage: 1.71 V to 5.5 V USB 2.0-certified, Full-Speed (12 Mbps) Supports native Billboard Device Class Driver Operating temperature: Integrated USB termination resistors Commercial: 0 C to 70 C 2 CY7C65210/210A: Single-channel I C interface Industrial: 40 C to 85 C Master up to 400 kHz ESD protection: 2.2-kV HBM 190 bytes for each transmit and receive buffer RoHS-compliant package 2 CY7C65217/217A: Dual-channel UART/I C interface 24-pin QFN (4.0 mm 4.0 mm, 0.55 mm, 0.5-mm pitch) UART interface Ordering part number Supports 2 pin CY7C65210-24LTXI Data rates up to 115200 bps CY7C65217-24LTXI 190 bytes for each transmit and receive buffer CY7C65210A-24LTXI Data format: 7 or 8 data bits, 1 or 2 stop bits CY7C65217A-24LTX No parity, even, odd, mark, or space parity Supports parity, overrun, and framing errors Applications Supports single-channel RS-232 and RS-422 interface 2 Any Type-C Device Container that supports Alternate Mode I C Interface requires Billboard Device support such as: Master up to 400 kHz Dongles for Type-C 190 bytes for each transmit and receive buffer Docking Stations General-purpose input/output (GPIO) pins: CY7C65210: 9 Monitors CY7C65217: 7 CY7C65210A: 11 Functional Description CY7C65217A: 9 1 The CY7C6521x is a Full-Speed USB controller, which 2560 bytes flash for storing configuration parameters enumerates as a Billboard Device. It integrates a voltage regulator, an oscillator, and flash memory for storing Billboard Device Class-specific descriptors configuration parameters, offering a cost-effective solution. Driver support for Billboard Device CY7C6521x supports bus-powered mode and enables efficient system power management with suspend and remote wake-up Billboard Device Class is natively supported by Windows 10 signals. It is available in a 24-pin QFN package. Clocking: Integrated 48-MHz clock oscillator For a complete list of related resources, click here. Supports bus- or self-powered configurations Comparison of Billboard Parts Feature CY7C65210 CY7C65217 CY7C65210A CY7C65217A Billboard Spec 1.1 1.1 1.21 1.21 Number of GPIOs 9 7 11 9 Suspend/Wakeup Support Yes Yes No* No* * Because these features are not relevant to Billboard, support for these features is removed. Note 1. CY7C6521x refers to CY7C65210, CY7C65217, CY7C65210A, and CY7C65217A. Cypress Semiconductor Corporation 198 Champion Court San Jose, CA 95134-1709 408-943-2600 Document Number: 001-97082 Rev. *F Revised April 2, 2018
