NTE2665 Silicon NPN Transistor Horizontal Deflection Output for High Resolution Display, Color TV Features: High Voltage: V = 1700V CBO Low Saturation Voltage: V = 3V Max CE(sat) High Speed: t = 0.1 s Typ f Absolute Maximum Ratings: (T = +25 C unless otherwise specified) C Collector-Base Voltage, V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1700V CBO Collector-Emitter Voltage, V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800V CEO Emitter-Base Voltage, V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V EBO Collector Current, I C Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28A Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56A Base Current, I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14A B Collector Power Dissipation, P . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220W C Operating Junction Temperature, T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150 C J Storage Temperature Range, T . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55 to +150 C stg Note 1. Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the significant change in temperature, etc.) may cause this product to decrease in the reli ability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the Absolute Maximum Ratings. Electrical Chracteristics: (T = +25 C unless otherwise specified) C Parameter Symbol Test Conditions Min Typ Max Unit Collector Cutoff Current I V = 1700V, I = 0 - - 1 mA CBO CB E Emitter Cutoff Current I V = 5V, I = 0 - - 100 A EBO EB C Collector-Emitter Breakdown Voltage V I = 10mA, I = 0 800 - - V (BR)CEO C B DC Current Gain h V = 5V, I = 2A 22 - 48 FE CE C V = 5V, I = 8A 12.5 - 25.0 CE C V = 5V, I = 22A 4.5 - 7.5 CE C Collector-Emitter Saturation Voltage V I = 22A, I = 5.5A - - 3 V CE(sat) C B Base-Emitter Saturation Voltage V I = 22A, I = 5.5A - 1.0 1.5 V BE(sat) C B Transition Frequency f V = 10V, I = 100mA - 2 - MHz T CE C Collector Outptut Capacitance C V = 10V, I = 0, f = 1MHz - 470 - pF ob CB EElectrical Chracteristics (Cont d): (T = +25 C unless otherwise specified) C Parameter Symbol Test Conditions Min Typ Max Unit Switching Time Storage Time t - 2.6 3.0 s I = 10A, I (end) = 1.4A, stg CP B1 f = 64kHz H Fall Time t - 0.2 0.3 s f Storage Time t I = 8A, I (end) = 1.2A, - 1.4 1.6 s stg CP B1 f = 130kHz H Fall Time t - 0.10 0.15 s f .807(20.5) Max .205 (5.2) Max .236 (6.0) 1.024 (26.0) .130 (3.3) Dia .098 (2.5) .787 (20.0) .215 (5.45) .039(1.0) .023 (0.6) BC E Note: Pin2 connected to heat sink
