SiHG22N50D www.vishay.com Vishay Siliconix D Series Power MOSFET FEATURES PRODUCT SUMMARY Optimal Design V (V) at T max. 550 DS J - Low Area Specific On-Resistance R max. at 25 C ()V = 10 V 0.230 DS(on) GS - Low Input Capacitance (C ) iss Q max. (nC) 98 g - Reduced Capacitive Switching Losses Q (nC) 13 gs - High Body Diode Ruggedness Q (nC) 22 gd - Avalanche Energy Rated (U ) IS Configuration Single Optimal Efficiency and Operation - Low Cost - Simple Gate Drive Circuitry TO-247AC - Low Figure-Of-Merit (FOM): R x Q on g D - Fast Switching Material categorization: For definitions please see www.vishay.com/doc 99912 G APPLICATIONS S D Consumer Electronics G - Displays (LCD or Plasma TV S Server and Telecom Power Supplies - SMPS N-Channel MOSFET Industrial - Welding, Induction Heating, Motor Drives Battery Chargers ORDERING INFORMATION Package TO-247AC SiHG22N50D-E3 Lead (Pb)-free Lead (Pb)-free and Halogen-free SiHG22N50D-GE3 ABSOLUTE MAXIMUM RATINGS (T = 25 C, unless otherwise noted) C PARAMETER SYMBOLLIMITUNIT Drain-Source Voltage V 500 DS V Gate-Source Voltage 30 V GS Gate-Source Voltage AC (f > 1 Hz) 30 T = 25 C 22 C Continuous Drain Current (T = 150 C) V at 10 V I J GS D T = 100 C 14 A C a Pulsed Drain Current I 67 DM Linear Derating Factor 2.5 W/C b Single Pulse Avalanche Energy E 139 mJ AS Maximum Power Dissipation P 312 W D Operating Junction and Storage Temperature Range T , T - 55 to + 150 C J stg Drain-Source Voltage Slope T = 125 C 24 J dV/dt V/ns d Reverse Diode dV/dt 0.38 c Soldering Recommendations (Peak Temperature) for 10 s 300 C Notes a. Repetitive rating pulse width limited by maximum junction temperature. b. V = 50 V, starting T = 25 C, L = 2.3 mH, R = 25 , I = 11 A. DD J g AS c. 1.6 mm from case. d. I I , dI/dt = 100 A/s, starting T = 25 C. SD D J S12-1459-Rev. A, 18-Jun-12 Document Number: 91516 1 For technical questions, contact: hvm vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000SiHG22N50D www.vishay.com Vishay Siliconix THERMAL RESISTANCE RATINGS PARAMETER SYMBOLTYP. MAX. UNIT Maximum Junction-to-Ambient R -40 thJA C/W Maximum Junction-to-Case (Drain) -0.4 R thJC SPECIFICATIONS (T = 25 C, unless otherwise noted) J PARAMETER SYMBOLTEST CONDITIONS MIN.TYP.MAX.UNIT Static Drain-Source Breakdown Voltage V V = 0 V, I = 250 A 500 - - V DS GS D V /T -0.6 - V Temperature Coefficient Reference to 25 C, I = 250 A V/C DS DS J D Gate-Source Threshold Voltage (N) V V = V , I = 250 A 3 - 5 V GS(th) DS GS D Gate-Source Leakage I V = 30 V - - 100 nA GSS GS V = 500 V, V = 0 V - - 1 DS GS Zero Gate Voltage Drain Current I A DSS V = 400 V, V = 0 V, T = 125 C - - 10 DS GS J Drain-Source On-State Resistance R V = 10 V I = 11 A - 0.185 0.230 DS(on) GS D Forward Transconductance g V = 50 V, I = 11 A - 8 - S fs DS D Dynamic Input Capacitance C - 1938 - iss V = 0 V, GS Output Capacitance C -V = 100 V, 169- oss DS f = 1 MHz Reverse Transfer Capacitance C -18- rss pF Effective Output Capacitance, Energy C - 144 - o(er) a Related V = 0 V to 400 V, V = 0 V DS GS Effective Output Capacitance, Time C - 210 - b o(tr) Related Total Gate Charge Q -49 98 g Gate-Source Charge Q -1V = 10 V I = 11 A, V = 400 V3- nC gs GS D DS Gate-Drain Charge Q -22- gd Turn-On Delay Time t -21 42 d(on) Rise Time t -42 84 r V = 380 V, I = 11 A, DD D ns Turn-Off Delay Time t -4V = 10 V, R = 4.7 794 d(off) GS g Fall Time t -4080 f Gate Input Resistance R f = 1 MHz, open drain - 1.4 - g Drain-Source Body Diode Characteristics MOSFET symbol D Continuous Source-Drain Diode Current I -- 22 S showing the A G integral reverse Pulsed Diode Forward Current I -- 88 S SM p - n junction diode Diode Forward Voltage V T = 25 C, I = 11 A, V = 0 V - - 1.2 V SD J S GS Reverse Recovery Time t - 384 - ns rr T = 25 C, I = I = 11 A, J F S Reverse Recovery Charge Q -4.7 - C rr dI/dt = 100 A/s, V = 20 V R Reverse Recovery Current I -23 - A RRM Notes a. C is a fixed capacitance that gives the same energy as C while V is rising from 0 % to 80 % V . oss(er) oss DS DSS b. C is a fixed capacitance that gives the same charging time as C while V is rising from 0 % to 80 % V . oss(tr) oss DS DSS S12-1459-Rev. A, 18-Jun-12 Document Number: 91516 2 For technical questions, contact: hvm vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc 91000
