CY62128EV30 MoBL 1-Mbit (128K 8) Static RAM 1-Mbit (128K 8) Static RAM Features Functional Description Very high speed: 45 ns The CY62128EV30 is a high performance CMOS static RAM module organized as 128K words by 8-bits. This device features Temperature ranges: advanced circuit design to provide ultra low active current. This Industrial: 40 C to +85 C is ideal for providing More Battery Life (MoBL ) in portable applications such as cellular telephones. The device also has an Wide voltage range: 2.2 V to 3.6 V automatic power-down feature that significantly reduces power Pin compatible with CY62128DV30 consumption when addresses are not toggling. Placing the device in standby mode reduces power consumption by more Ultra low standby power than 99 percent when deselected (CE HIGH or CE LOW). The 1 2 Typical standby current: 1 A eight input and output pins (I/O through I/O ) are placed in a 0 7 Maximum standby current: 4 A high impedance state when the device is deselected (CE HIGH 1 or CE LOW), the outputs are disabled (OE HIGH), or a write 2 Ultra low active power operation is in progress (CE LOW and CE HIGH and WE 1 2 Typical active current: 1.3 mA at f = 1 MHz LOW). Easy memory expansion with CE , CE and OE features 1 2, To write to the device, take chip enable (CE LOW and CE 1 2 HIGH) and write enable (WE) inputs LOW. Data on the eight I/O Automatic power-down when deselected pins is then written into the location specified on the address pin Complementary metal oxide semiconductor (CMOS) for (A through A ). 0 16 optimum speed and power To read from the device, take chip enable (CE LOW and CE 1 2 Offered in Pb-free 32-pin small outline integrated circuit (SOIC), HIGH) and output enable (OE) LOW while forcing write enable 32-pin thin small outline package (TSOP) Type I, and 32-pin (WE) HIGH. Under these conditions, the contents of the memory shrunk thin small outline package (STSOP) packages location specified by the address pins appear on the I/O pins. For a complete list of related resources, click here. Logic Block Diagram INPUT BUFFER I/O 0 A 0 A I/O 1 1 A 2 A I/O 3 2 A 4 A 128K x 8 I/O 5 3 A 6 A ARRAY I/O 7 4 A 8 A I/O 9 5 A 10 A I/O 11 6 CE 1 I/O POWER CE 7 2 COLUMN DECODER WE DOWN OE Cypress Semiconductor Corporation 198 Champion Court San Jose, CA 95134-1709 408-943-2600 Document Number: 38-05579 Rev. *P Revised March 29, 2019 ROW DECODER A 12 A 13 A 14 A 15 A 16 SENSE AMPS CY62128EV30 MoBL Contents Pin Configuration .............................................................3 Ordering Information ...................................................... 12 Product Portfolio ..............................................................3 Ordering Code Definitions ......................................... 12 Maximum Ratings .............................................................4 Package Diagrams .......................................................... 13 Operating Range ...............................................................4 Acronyms ........................................................................ 16 Electrical Characteristics .................................................4 Document Conventions ................................................. 16 Capacitance ......................................................................5 Units of Measure ....................................................... 16 Thermal Resistance ..........................................................5 Document History Page ................................................. 17 AC Test Loads and Waveforms .......................................5 Sales, Solutions, and Legal Information ...................... 20 Data Retention Characteristics .......................................6 Worldwide Sales and Design Support ....................... 20 Data Retention Waveform ................................................6 Products .................................................................... 20 Switching Characteristics ................................................7 PSoC Solutions ...................................................... 20 Switching Waveforms ......................................................8 Cypress Developer Community ................................. 20 Truth Table ......................................................................11 Technical Support ..................................................... 20 Document Number: 38-05579 Rev. *P Page 2 of 20
