CBTL08GP053 USB Type-C High performance Crossbar Switch IC Rev. 2 1 August 2016 Product data sheet 1. General description CBTL08GP053 is a USB Type-C High Performance Crossbar Switch IC meant to be used for Type-C connector interface high speed passive switching applications. It provides switching of high speed differential signals that correspond to various interface standards: USB3.1 (10 Gbps), DP1.3 (8.1 Gbps), PCI Express 3.0 (8 Gbps), etc. It supports switching of single ended signals over Type-C interface. In addition, side band switching of AUX and other dedicated signals for transport over SBU1 and SBU2. 2 It provides the I C-bus interface for switch control, configuration and status update. It operates from a single platform power supply V . DD This IC is targeted for a wide range of platforms (PCs, tablets, convertibles, smart phones) and PC accessories (e.g. docks, monitors, etc.) applications. CBTL08GP053 is available in a small footprint package option: VFBGA40 4.75 mm 3.25 mm, 0.5 mm pitch. 2. Features and benefits 2.1 High speed switch features Supports the following interface standards: USB3.1, DP1.3, DP++, PCIe 3.0 Supports signaling rates up to 10 Gbps Performs multiplexing or switching of high speed differential signals or single ended signals All switches are direction agnostic Design based on both patented and patent pending high performance switch technology Target performance specification Differential signaling (peak to peak) of 1.4 V and common mode level over 0 V to 2.2 V 1.8 V single ended rail to rail signaling R : 7 (typ) on Insertion loss: 1.2 dB at 2.7 GHz, 1.8 dB at 5.4 GHz, 3dB at 8.5 GHz (typ) Isolation: 23 dB at 2.7 GHz, 16.5 dB at 5.4 GHz (typ) Cross talk: 32 dB at 2.7 GHz, 24 dB at 5.4 GHz (typ) Return loss: 20 dB at 2.7 GHz, 16 dB at 5.4 GHz (typ) Very low intra pair skew Very low propagation delay (80 ps typical) and inter pair skew (35 ps typical) CBTL08GP053 NXP Semiconductors USB Type-C High performance Crossbar Switch IC 2 Switch paths selectable through the I C-bus interface (registers for atomic and sequential switch selection) 2.2 Sideband auxiliary crossbar switch features Single ended 2:1 multiplexing/switching with single ended cross bar switching of both differential AUX or single ended UART or I2C or miscellaneous signals Switches are direction agnostic Switches are 5.5 V tolerant Target performance specification (typical values) R 8 (typ) at V = 0.5 V to 2.65 V on cm Very low intra pair skew Very low propagation delay (80 ps typical) 2 Switch paths selectable through the I C-bus interface (registers for atomic and sequential switch selection) 2.3 General Supports I2C slave interface Standard mode (100 kbit/s) and Fast mode (400 kbit/s) I2C slave address programmable up to 4 values Back current protection on control pins and exposed connector side I/O pins Single 3.3V power supply Current consumption Active mode (all switches are functional): 300 A (typ) Standby mode (all switches in Hi-Z): 15 A (max) Operating temperature: 40 to 105 C ESD 2 kV HBM, 500 V CDM Package: VFBGA40 4.75 mm 3.25 mm, 0.5 mm pitch 3. Applications PC platforms: notebook PCs, desktop PCs, ultrabooks Tablets, 2:1 convertibles, smartphones and portable devices PC accessories/peripherals: multi-function monitors, etc. CBTL08GP053 All information provided in this document is subject to legal disclaimers. NXP Semiconductors N.V. 2016. All rights reserved. Product data sheet Rev. 2 1 August 2016 2 of 38
